Fox Bollard

Fox-Bollards

Fox-B-6W-500, Fox-B-6W-750

Fox-Bollards

Product Overview

Fox Bollards are beautifully crafted from 2mm thick High purity Aluminium tube, machine swaged with Cast Aluminium LED top Housing to create a sleek high output LED Floorwasher, available with integral 240VAC driver or remote ELV -24VDC version. Integral IP54 198-264VAC > 24VDC driver within the ⌀40 x 500mm tall aluminium stem LV Constant Voltage IP65 led array - 927 / 930 / 940K, 3 or 6W versions 125mm circular led array, 3W / 265lms, 6W / 530lms Swaged tube assembly Dia 14>40mm x 500 or 750mm with Dia 10mm spike assembly, side cable exit supplied pre-fitted with 10M 2 core Black Butyl rubber 0.75mm flex (3182TQ/75) Life - >50,000 hours (5 year manufacturers warranty) Selection of anodised finishes (can mix & Match LED housing and Swaged stem Special versions including BS/RAL finishes on request

£385

1
Add to Cart
Technical Specifications

Wattage

  • 6W

Output

  • 530

Typical Efficacy (lm/W)

    Other Technical Details

    CCT/CRI Options (K)
    • 2700/3000/3500
    Beam Angles (º)
    • floor wash
    Finishes (Baffle)
    • N/A
    Finishes (Body/Bezel)
    • Anodised silver - ANS
    • Anodised Black - ANB
    • Anodised Copper - ANC
    • Anodised Rich Gold -ANG
    • Anodised Champagne Gold - ANCG
    • Anodised red - ANR
    • Any BS/RAL finish to order
    Accessories
    • N/A
    IP Rating
    • 65
    Location (Ceiling/Wall/Floor)
      Input Voltage/Current
      • 240VAC/50Hz
      • 24VDC
      Energy Efficiency Class
        Control / Driver Options
        • Integrated CV driver - SW
        • remote 24VDC driver - 24V
        Dimensions
        • FOX-B-6W-500 - Dia125 x 506mm
        • FOX-B-6W-750 - Dia125 x 756mm
        Typ Product Code
        • Fox-B-6W-500/2700/ANCG/SW
