POLYFLUX D25 Rotundo - Dynamic White - 2700K & 5000K
Product Overview
POLYFLUX DIA-25MM dynamic white flexible Polyurethane NEON. CV only - DC24V, 5W & 5W/M, Diameter 25, 50mm modules (20 modules / M), 140LEDS/M, CRI>90, LUMILEDS 2835, 2 Step binning, multiple axis Bending, 30cm, 3 core Open Wire from Both Ends, End Cable Entry, IP65, 5 Years Warranty. Available with End or Side cable entry (EE/SE) -Max Run Length 10W = 5M
Technical Specifications
Electrical Performance
Wattage
5W+5W
Lumen Output
Dynamic White 10W•M•- 5W-2700K-258lm•M•5W-5000K-262lm•M
Input Voltage/Current
24VDC
Typical Efficacy (lm/W)
Other Technical Details
| SPECIFICATION | DETAILS |
|---|---|
| CCT/CRI Options (K) | 927&850 |
| Beam Angles (º) | 360 |
| Finishes (Baffle) | matt white |
| Accessories | Polyflux D25 Polycarbonate Profile - LxWxH 2000x30x27.4mm - PF-D25PC-Profile2MPolyflux D25 Open Polycarbonate clips - LxWxH 20x30x27.4mm - PF-D25PC-O-clips20mm (4pcsbag)Polyflux D25 Closed Polycarbonate clips - - PF-D25PC-C-clips20mm (4pcsbag)Polyflux D25 Open Polycarbonate clips - suspension sets - - PF-D25PC-O-Susp kits20mm (2pcsbag)Polyflux D25 Closed Polycarbonate clips - suspension sets - - PF-D25PC-C-Susp kits20mm (2pcsbag)Ceiling Mounted Collet suspension node: Machined from Aluminium alloy - allows factory assembled PF-D25 to pass through collet and twist to lockUnlock. |
| IP Rating | IP65 |
| Energy Efficiency Class | G>F |
| Control / Driver Options | Triac (TR)0-10V (010)DALI (DA)Bluetooth (BT)DMX (DMX) |
| Dimensions | Dia 25 x Max5M |
| Typ Product Code | PF-D252*5WDWEE5000mm |
